4 en | Table of contents MAP 5000
2016.06 | 17 | F.01U.168.332 Installation manual Bosch Sicherheitssysteme GmbH
4.2.2 Standard-compliant programming 59
4.3 Panel software 59
4.3.1 Checking the software version 59
4.3.2 Software updates 60
4.3.3 Manufacturer authorization 60
4.4 Completing the installation 60
4.5 Point types and point evaluation 60
4.6 Output functions 61
4.6.1 Programmable output signals 61
4.6.2 Sirens and communicator in accordance with EN50131 grade 3 63
5
Enclosure options 65
5.1 ICP-MAP0115 power enclosure 65
5.2 Rack mount option for ICP-MAP0120 expansion enclosure 66
6
Maintenance and service 67
6.1 General information 67
6.2 Installer button 67
7
Technical Specifications 69
8
Appendices 72
8.1 Requirements in accordance with VdS class C 72
8.1.1 Selecting the default setting 72
8.1.2 Power supply for areas 72
8.1.3 Control centers and display panel 72
8.1.4 Connection to a management system 72
8.1.5 Printer connection 72
8.1.6 Access levels 72
8.2 Requirements in accordance with EN 50131 grade 3 75
8.2.1 Selecting the default setting 75
8.2.2 Connectable peripherals 75
8.2.3 Arming / disarming without entry / exit delay 75
8.2.4 Arming / disarming with entry / exit delay 75
8.2.5 Arming with automatic bypass 77
8.2.6 Automatic arming / disarming 77
8.2.7 Alarm output via siren and communicator 78
8.2.8 Connection to a management system 78
8.2.9 Printer connection 78
8.2.10 Access levels 78
8.2.11 Additional functions of the main panel 81
8.3 Requirements in accordance with SES 81
8.3.1 Selecting the default setting 81
8.3.2 Automatic arming / disarming 82
8.3.3 Areas with blocking time 82
8.3.4 Access Levels 82
8.3.5 Tamper surveillance of the main panel 85
8.4 Alarm reporting 86
