10.4 Rules and Standards
10.4.1 Overall system conformance
– Conforms to IEC60914, the international standard for conference systems
– Conforms to IEC61603 part7, the international standard for digital infrared transmission
of audio signals for conference and similar applications
10.5 Guaranteed rectangular footprints
10.5.1 Metric values of radiators with hardware version higher than 2.00
LBB 4511/00 at full power LBB 4512/00 at full power
Nr. H a A L W X A L W X
1 2,5 0 814 37 22 8,5 1643 53 31 11,5
5 15 714 34 21 8 1440 48 30 10,5
30 560 28 20 5 1026 38 27 6,5
45 340 20 17 2 598 26 23 3
60 240 16 15 -0,5 380 20 19 0
90 169 13 13 -6,5 196 14 14 -7
10 15 770 35 22 10 1519 49 31 12,5
30 651 31 21 6 1189 41 29 8
45 480 24 20 2,5 837 31 27 3
60 380 20 19 -1,5 600 25 24 -1
90 324 18 18 -9 441 21 21 -10,5
20 30 609 29 21 12 1364 44 31 11
45 594 27 22 6 1140 38 30 4,5
60 504 24 21 0,5 899 31 29 -1,5
90 441 21 21 -10,5 784 28 28 -14
2 2,5 15 360 24 15 5 714 34 21 7
5 15 375 25 15 6 714 34 21 8
30 294 21 14 4 560 28 20 5
45 195 15 12 1,5 340 20 17 2
60 156 13 12 -1 240 16 15 -0,5
90 121 11 11 -5,5 169 13 13 -6,5
10 30 330 22 15 5,5 651 31 21 6
45 285 19 15 2,5 480 24 20 2,5
60 224 16 14 -1 380 20 19 -1,5
90 196 14 14 -7 324 18 18 -9
20 60 255 17 15 2,5 504 24 21 0,5
