Bosch MSM019A - Motor encoder M5

6.2 Motor encoder M5
Data sheet - Encoder
Designation Symbol Unit Encoder M5 (MSM)
Battery extern - Yes
Encoder design - - Singleturn absolute Multiturn absolute
Distinguishable revolu‐
tions
- - 1 65536
Incremental signals - - without
Resolution of encoder - - 20 bit 20 + 16 bit
System accuracy typical/
maximum
- “ -170 / -240
Maximum encoder speed
min
-1
6000
Supply voltage
VCC
Encoder
V 4.5 … 5.5
Max. current consumption
I
Encoder
mA 70
Latest amendment: 2017-09-21
“ Angular seconds
Tab. 6-2: Encoder data
Singleturn absolute value encoder
The singleturn absolute value encoder serves for absolute indirect position
detection within 1 motor revolution. For this encoder variant, the absolute axis
position gets lost after switching-off the voltage.
Multiturn absolute value encoder
The multiturn absolute value encoder serves for absolute indirect position de‐
tection within 65536 motor revolutions. The absolute axis position at this en‐
coder variant is retained by the battery buffering even after switching-off the
voltage. If the motor is disconnected from the batterybos, the information
about absolute axis position gets lost after about 1 minute. It replaces a sepa‐
rate absolute value encoder at the motor.
Details for multiturn signals
For using the multiturn option, the buffering memory via a necessary battery
is necessary. Therefore, the following accessory must be used:
Batterybox
Designation Order number Length
SUP-E02-MSM-BATTERYBOX-L010 R911346063 1000 mm
SUP-E02-MSM-BATTERYBOX-L030 R911346065 3000 mm
SUP-E02-MSM-BATTERYBOX-NNNN R911346084 250 mm
Spare battery
Designation Order number
SUP-E02-MSM-BATTERY R911369925
Bosch Rexroth AG DOK-MOTOR*-MSM********-DA05-EN-P36/61
Synchronous Servomotors MSM
Motor encoder MSM
