Bosch MSM019A - MSM041 Specifications

5.4.2 MSM041 Specifications
MSM041...M0-C...
Motor / size A B C D E F G H J K
MSM041B-...-..-M0-CH0 □80 112 35
ø19
h6
ø70
h7
ø90±0.20 ø6 93 25.5 52.2
MSM041B-...-..-M0-CH1 □80 149 35
ø19
h6
ø70
h7
ø90±0.20 ø6 93 25.5 52.2
Motor / size L M N T U
MSM041B-...-..-M0-CH0 36 3 8 200 220
MSM041B-...-..-M0-CH1 36 3 8 200 220
Tab. 5-12: Dimensions MSM041
DOK-MOTOR*-MSM********-DA05-EN-P Bosch Rexroth AG 33/61
Synchronous Servomotors MSM
Technical data
