Bosch MSM019A - MSM041 Technical Data

5.4 MSM041
5.4.1 MSM041 Technical data
Designation Symbol Unit MSM041B-0300-NN
Cooling mode acc. to EN 60034-6 - IC00
Listed acc. to UL standard - UL 1004; ANSI UL 840
Listed acc. to CSA standard - CSA-C22,2 No, 100
UL-Files E335445
Electrical parameters
Rated power
P
N
kW 0.75
Continuous torque at standstill 60 K
M
0_60
Nm 2.40
Continuous current at standstill 60 K
I
0_60(eff)
A 4.00
Maximum current
I
max(eff)
A 12.00
Maximum torque
M
max
Nm 7.10
Torque constant at 20 °C
K
M_N
Nm/A 0.64
Voltage constant at 20 °C
1)
K
EMK_1000
V/min
-1
37.6
Winding resistance at 20 °C
R
12
Ohm 1.50
Winding inductance
L
12
mH 6.700
Discharge capacity of the component
C
dis
nF 1.3
Number of pole pairs p - 4
Mechanical parameters
Moment of inertia of rotor
2)
J
rot
kg*m
2
0.0000870
Wire cross section
A
60
mm
2
0.75
Maximum speed (electrical)
n
max el
min
-1
4500
Mass
3)
m kg 2.3 ( 3.1 )
Storage temperature
T
L
°C -20 ... +60
Ambient temperature during operation
T
amb
°C 0 ... 40
Installation altitude m 0 ... 1000
Thermal class (EN 60034-1) T.CL. - 130 (B)
Protection class acc. to IEC 60529 IP - IP54
Sound pressure level
L
P
dB[A] < 70
Latest amendment: 2019-02-14
1) Manufacturing tolerance ±5%
2) Tolerance ± 10%
3) (...) Motors with holding brake 1, 2, ...
Tab. 5-10: MSM - Technical data
DOK-MOTOR*-MSM********-DA05-EN-P Bosch Rexroth AG 31/61
Synchronous Servomotors MSM
Technical data
