6 Motor encoder MSM
6.1 Motor encoder M0
Data sheet - Encoder
Designation Symbol Unit Encoder M0 (MSM)
Battery extern - Yes
Encoder design - - Singleturn absolute Multiturn absolute
Distinguishable revolu‐
tions
- - 1 65536
Incremental signals - - without
Resolution of encoder - - 17 bit 17+16 bit
System accuracy - “ tbd
Maximum encoder speed
min
-1
6000
Supply voltage
VCC
Encoder
V 4.75 … 5.25
Max. current consumption
I
Encoder
mA 70
Latest amendment: 2009-07-07
“ Angular seconds
Tab. 6-1: Encoder data
Singleturn absolute value encoder
The singleturn absolute value encoder serves for absolute indirect position
detection within 1 motor revolution. For this encoder variant, the absolute axis
position gets lost after switching-off the voltage.
Multiturn absolute value encoder
The multiturn absolute value encoder serves for absolute indirect position de‐
tection within 65536 motor revolutions. It replaces a separate absolute value
encoder at the motor. The absolute axis position at this encoder variant is re‐
tained by the battery buffering even after switching-off the voltage. If the mo‐
tor is disconnected from the batterybos, the information about absolute axis
position gets lost after about 1 minute.
Details for multiturn signals
For using the multiturn option, the buffering memory via a necessary battery
is necessary. Therefore, the following accessory is available:
Batterybox
Designation Order number
SUP-E01-MSM-BATTERYBOX R911324240
Spare battery
Designation Order number
SUP-E03-DKC*CS-BATTRY R911295648
