0°
0°
210°
-30°
30°
-210°
0°
220°
-20°
30°
0°
-210°
P
P
E
E
P: RLS1100
E: RGS1000
P: RLS1200
E: RGS1000
Fig. 9-2: Adjustment range of flange socket, rotatable
Flange socket
Twisting moment
1)
maximum [Nm]
RGS1000
RLS1100
12
RLS1200 18
1) Maximum torque to change the orientation of the flange sock‐
ets
Tab. 9-7: Twisting moments of flange sockets
