Bosch Rexroth MSK - 5.27 MSK101 D-...-NSNN Technical data

5.27 MSK101D-...-NSNN Technical data
Designation Symbol Unit MSK101D-0200-NN MSK101D-0301-NN
Continuous torque at standstill 60 K
M
0_60
Nm 50.0
Continuous current at standstill 60 K
I
0_60(eff)
A 22.2 30.6
Maximum torque
M
max
Nm 160.0
Maximum current
I
max(eff)
A 99.9 137.7
Torque constant at 20 °C
K
M_N
Nm/A 2.48 1.80
Voltage constant at 20 °C
1)
K
EMK_1000
V/1000
min-1
152.0 113.0
Winding resistance at 20 °C
R
12
Ohm 0.35 0.19
Winding inductance
L
12
mH 6.0 3.2
Leakage capacitance of the compo‐
nent
C
dis
nF 13.2 9.1
Number of pole pairs p - 4
Moment of inertia of rotor
J
red
kg*m
2
0.00932
Thermal time constant
T
th
min 100.0
Maximum speed (electric)
n
max el
min
-1
3400 4000
Sound pressure level
L
P
dB[A] < 75
Mass
2)
m kg 40.0 (43.8) (46.2)
Ambient temperature during operation
T
amb
°C 0 ... 40
Protection class (EN 60034‑5) - - IP65
Thermal class (EN 60034‑1) T.CL. - 155
Last amended: 2014-01-21
1) Manufacturing tolerance ±5%
2) (...) Motors with holding brake 1, 2, ...
Tab. 5-78: Technical data MSK101D-...-NSNN
Tab. 5-79: Technical data MSK101D-0200-__-__-___-_S__
Bosch Rexroth AG DOK-MOTOR*-MSK*EXGIIK3-PR09-EN-P78/175
Synchronous Servomotors MSK For Potentially Explosive Areas
Technical data
