Bosch Rexroth MSK - 5.16 MSK070 C-...-NSNN Technical data

5.16 MSK070C-...-NSNN Technical data
Designation Symbol Unit MSK070C-0150-NN MSK070C-0300-NN MSK070C-0450-NN
Continuous torque at standstill 60 K
M
0_60
Nm 13.0
Continuous current at standstill 60 K
I
0_60(eff)
A 4.1 8.2 12.3
Maximum torque
M
max
Nm 33.0
Maximum current
I
max(eff)
A 12.6 25.0 36.9
Torque constant at 20 °C
K
M_N
Nm/A 3.47 1.74 1.16
Voltage constant at 20 °C
1)
K
EMK_1000
V/1000
min-1
213.2 107.0 71.3
Winding resistance at 20 °C
R
12
Ohm 4.7 1.13 0.55
Winding inductance
L
12
mH 34.9 8.3 4.0
Leakage capacitance of the compo‐
nent
C
dis
nF 3.8 4.0 3.1
Number of pole pairs p - 6
Moment of inertia of rotor
J
red
kg*m
2
0.00291
Thermal time constant
T
th
min 22.0 31.0
Maximum speed (electric)
n
max el
min
-1
2,500 5,500 6000
Sound pressure level
L
P
dB[A] < 75
Mass
2)
m kg 11.7 (13.2)
Ambient temperature during operation
T
amb
°C 0 ... 40
Protection class (EN 60034‑5) - - IP65
Thermal class (EN 60034‑1) T.CL. - 155
Last amended: 2014-01-21
1) Manufacturing tolerance ±5%
2) (...) Motors with holding brake 1, 2, ...
Tab. 5-35: Technical data MSK070C-..-NSNN
Tab. 5-36: Technical data MSK070C-0150-__-__-___-_S__
DOK-MOTOR*-MSK*EXGIIK3-PR09-EN-P Bosch Rexroth AG 55/175
Synchronous Servomotors MSK For Potentially Explosive Areas
Technical data
