RE 30110-B/11.2012, VT-VSPA2-1-2X/V0/T., Bosch Rexroth AG
Table 13: Specification of the outputs
Denomination Value
Command value signal U ±10 V ±2 %; I
max
= 2 mA
Actual value signal U ±2.5 V ±2 %; I
max
= 2 mA; 1 mV = 1 mA
Measuring point signal (option T5) U ±10 V ±2 %; I
max
= 2 mA
Ready for operation U > 16 V, 50 mA; (in case of fault < 1 V, R
i
= 10 kΩ)
Regulated voltages U +10 V ±2 %; 25 mA; short-circuit-proof
+10 V ±2 %; 25 mA; short-circuit-proof
Power output stage I 0 to 2.5 mA; short-circuit-proof, clocked
Measuring sockets
Command value U ±10 V ±2 %; I
max
= 2 mA
Actual current value U ±2.5 V ±2 %; I
max
= 2 mA (mV ≙ mA)
15 Appendix
15.1 List of addresses
15.1.1 Contacts for repairs and support
Bosch Rexroth AG
Service Industriehydraulik [Industrial hydraulics]
Bgm.-Dr.-Nebel-Straße 8
97816 Lohr am Main
Germany
Phone +49 (0) 9352 40 50 60
http://www.boschrexroth.com/service
Email: service@boschrexroth.de
