Bose PowerShare PS602P Service Manual

27
ELECTRICAL PART LIST
Resistors (continued)
Capacitors
Amplifier PCB Assembly, PS602/PS602P/PS604
Reference
Designator
Description Part Numbe
r
Note
R2108 0603, .1W, 1%, 200K 191465-2003
R2109 0603, .1W, 1%, 200K 191465-2003
R2111 0603, .1W, 1%, 82.5K 191465-8252
R2112 0603, .1W, 1%, 82.5K 191465-8252
R2113 0603, .1W, 1%, 4.99K 191465-4991
R2114 0603, .1W, 1%, 200K 191465-2003
R2115 0603, .1W, 1%, 200K 191465-2003
R2116 0603, .1W, 1%, 332 OHM 191465-3320
R2117 0603, .1W, 1%, 332 OHM 191465-3320
R2118 0603, .1W, 1%, 3.01K 191465-3011
R2119 0603, .1W, 1%, 3.01K 191465-3011
R2120 0603, .1W, 1%, 332 OHM 191465-3320
R2121 0603, .1W, 1%, 332 OHM 191465-3320
R2122 0603, .1W, 1%, 332 OHM 191465-3320
R2123 0603, .1W, 1%, 332 OHM 191465-3320
R2124 0603, .1W, 1%, 100 OHM 191465-1000
R2125 0603, .1W, 1%, 100 OHM 191465-1000
R2126 0603, 100MW, 1%, 1.33K 191465-1331
R2127 0603, 100MW, 1%, 1.33K 191465-1331
R2128 0603, .1W, 1%, 3.32K 191465-3321
R2129 0603, .1W, 1%, 1K 191465-1001
R2130 0603, .1W, 1%, 681 OHM 191465-6810
R2131 0603, .1W, 1%, 20K 191465-2002
R2132 0603, .1W, 1%, 681 OHM 191465-6810
R2133 0603, 100MW, 1%, 1.33K 191465-1331
R2134 0603, 100MW, 1%, 1.33K 191465-1331
R2135 0603, .1W, 1%, 49.9K 191465-4992
Reference
Designator
Description Part Number Note
C100 1206, X7R, 25V, 10%, 4.7uF 262063-475
C101 1206, X7R, 25V, 10%, 4.7uF 262063-475
C102 X7R, 0603, 10%, 0.1uF, 50V 191470-104
C103 0805, X7R, 50V, 0.1uF 133623-104
C104 X7R, 0603, 10%, 0.1uF, 50V 191470-104
C105 0805, X7R, 50V, 0.1uF 133623-104
C106 X7R, 0603, 10%, 0.1uF, 50V 191470-104
C107 0805, X7R, 50V, 0.1uF 133623-104
C108 C0G, 0603, 50V, 5%, 470pF 188454-471
C109 0805, X7R, 50V, 0.1uF 133623-104
C110 X7R, 1210, 25V, 10%, 22uF, COMM 759068-226K1E
C111 X7R, 0603, 10%, 0.1uF, 50V 191470-104
C112 X7R, 0603, 10%, 0.1uF, 50V 191470-104
C113 X7R, 0603, 16V, 10%, 1uF 257154-105K16
C114 X7R, 0805, 6.3V, 10%, 10uF 359399-106K
C115 X7R, 0603, 16V, 10%, 1uF 257154-105K16
C116 0805, X7R, 50V, 0.1uF 133623-104
C117 C0G, 0603, 50V, 5%, 470pF 188454-471
C118 X7R, 0805, 6.3V, 10%, 10uF 359399-106K
C119 0805, X7R, 50V, 0.1uF 133623-104
C120 X7R, 0603, 10%, 0.1uF, 50V 191470-104
