Bose PowerShare PS602P Service Manual

28
ELECTRICAL PART LIST
Capacitors (continued)
Amplifier PCB Assembly, PS602/PS602P/PS604
Reference
Designator
Description Part Numbe
r
Note
C121 0805, X7R, 50V, 0.1uF 133623-104
C122 1206, X7R, 25V, 10%, 4.7uF 262063-475
C123 X7R, 0603, 10%, 0.1uF, 50V 191470-104
C125 1206, X7R, 25V, 10%, 4.7uF 262063-475
C126 X7R, 0603, 10%, 0.1uF, 50V 191470-104
C127 X7R, 0603, 10%, 0.1uF, 50V 191470-104
C128 X7R, 0603, 10%, 0.1uF, 50V 191470-104
C129 0805, X7R, 10%, 25V, 1UF 181264-105
C130 1206, X7R, 25V, 10%, 4.7uF 262063-475
C131 X7R, 0603, 10%, 0.1uF, 50V 191470-104
C132 X7R, 0603, 10%, 0.1uF, 50V 191470-104
C133 0805, X7R, 10%, 25V, 1uF 181264-105
C134 C0G, 0603, 50V, 5%, 330pF 188454-331
C135 EL, 105C, 25V, 20%, 1000uF, 10mm DIA, CUT 196991-
102E6P50
C136 X7R, 0603, 10%, 0.1uF, 50V 191470-104
C137 1206, X7R, 25V, 10%, 4.7uF 262063-475
C138 0805, X7R, 50V, 0.1uF 133623-104
C139 C0G, 0603, 50V, 5%, 330pF 188454-331
C141 0805, X7R, 50V, 0.1uF 133623-104
C142 1206, X7R, 25V, 10%, 4.7uF 262063-475
C200 0603, X7R, 5%, 25V, 6800PF 196999-682
C201 0603, X7R, 5%, 25V, 6800PF 196999-682
C202 0603, X7R, 5%, 25V, 6800PF 196999-682
C203 0603, X7R, 5%, 25V, 6800PF 196999-682
C204 0805, X7R, 50V, 0.1uF 133623-104
C205 0805, X7R, 50V, 0.1uF 133623-104
C206 C0G, 0603, 50V, 5%, 2700pF 188454-272
C207 C0G, 0603, 50V, 5%, 2700pF 188454-272
C208 C0G, 0603, 50V, 5%, 2700pF 188454-272
C209 C0G, 0603, 50V, 5%, 2700pF 188454-272
C212 0805, X7R, 50V, 0.1uF 133623-104
C213 0805, X7R, 50V, 0.1uF 133623-104
C214 C0G, 0603, 50V, 5%, 270pF 188454-271
C215 C0G, 0603, 50V, 5%, 270pF 188454-271
C216 C0G, 0603, 50V, 5%, 270pF 188454-271
C217 C0G, 0603, 50V, 5%, 270pF 188454-271
C218 X7R, SMD, 5%, 25V, 0603, 68NF 196999-683
C219 X7R, SMD, 5%, 25V, 0603, 68NF 196999-683
C220 X7R, 1210, 25V, 10%, 22uF, COMM 759068-226K1E
C221 X7R, 1210, 25V, 10%, 22uF, COMM 759068-226K1E
C222 C0G, 0603, 50V, 5%, 510pF 188454-511
C223 C0G, 0603, 50V, 5%, 510pF 188454-511
C224 C0G, 0603, 50V, 5%, 390pF 188454-391
C225 C0G, 0603, 50V, 5%, 390pF 188454-391
C226 0805, X7R, 50V, 0.1uF 133623-104
C227 0805, X7R, 50V, 0.1uF 133623-104
C228 C0G, 0603, 50V, 5%, 560pF 188454-561
C229 C0G, 0603, 50V, 5%, 1000pF 188454-102
C230 C0G, 0603, 50V, 5%, 560pF 188454-561
C231 C0G, 0603, 50V, 5%, 560pF 188454-561
C232 C0G, 0603, 50V, 5%, 1000pF 188454-102
