Bose PowerShare PS602P Service Manual

29
ELECTRICAL PART LIST
Capacitors (continued)
Amplifier PCB Assembly, PS602/PS602P/PS604
Reference
Designator
Description Part Numbe
r
Note
C233 C0G, 0603, 50V, 5%, 560pF 188454-561
C234 C0G, 0603, 50V, 5%, 180pF 188454-181
C235 C0G, 0603, 50V, 5%, 180pF 188454-181
C236 C0G, 0603, 50V, 5%, 180pF 188454-181
C237 C0G, 0603, 50V, 5%, 1800pF 188454-182
C238 C0G, 0603, 50V, 5%, 270pF 188454-271
C239 C0G, 0603, 50V, 5%, 1800pF 188454-182
C240 C0G, 0603, 50V, 5%, 1800pF 188454-182
C241 C0G, 0603, 50V, 5%, 220pF 188454-221
C242 C0G, 0603, 50V, 5%, 270pF 188454-271
C243 C0G, 0603, 50V, 5%, 1800pF 188454-182
C244 C0G, 0603, 50V, 5%, 1800pF 188454-182
C245 C0G, 0603, 50V, 5%, 180pF 188454-181
C246 C0G, 0603, 50V, 5%, 1800pF 188454-182
C247 C0G, 0603, 50V, 5%, 1800pF 188454-182
C248 C0G, 0603, 50V, 5%, 1800pF 188454-182
C249 C0G, 0603, 50V, 5%, 1800pF 188454-182
C250 C0G, 0603, 50V, 5%, 220pF 188454-221
C251 C0G, 0603, 50V, 5%, 1800pF 188454-182
C252 C0G, 0603, 50V, 5%, 1800pF 188454-182
C253 C0G, 0603, 50V, 5%, 1800pF 188454-182
C254 C0G, 0603, 50V, 5%, 470pF 188454-471
C255 C0G, 0603, 50V, 5%, 470pF 188454-471
C256 C0G, 0603, 50V, 5%, 220pF 188454-221
C257 C0G, 0603, 50V, 5%, 220pF 188454-221
C258 C0G, 0603, 50V, 5%, 10pF 188454-100
C259 X7R, 0603, 10%, 0.1uF, 50V 191470-104
C260 X7R, 0603, 10%, 0.1uF, 50V 191470-104
C261 C0G, 0603, 50V, 5%, 10pF 188454-100
C262 X7R, 0603, 10%, 0.1uF, 50V 191470-104
C263 X7R, 0603, 10%, 0.1uF, 50V 191470-104
C264 0805, X7R, 10%, 25V, 1uF 181264-105
C265 0603, C0G, SMD, 25V, 5%, 10nF 268368-103
C266 0603, C0G, SMD, 25V, 5%, 10nF 268368-103
C267 0805, X7R, 50V, 0.1uF 133623-104
C268 0805, X7R, 10%, 25V, 1uF 181264-105
C269 C0G, 0603, 50V, 5%, 82pF 188454-820
C270 0603, X7R, 50V, .01uF 191470-103
C271 C0G, 0603, 50V, 5%, 82pF 188454-820
C272 C0G, 0603, 50V, 5%, 10pF 188454-100
C273 C0G, 0603, 50V, 5%, 10pF 188454-100
C274 C0G, 0603, 50V, 5%, 1800pF 188454-182
C275 C0G, 0603, 50V, 5%, 1800pF 188454-182
C300 0603, X7R, 50V, 10%, .033uF 191470-333
C301 0603, X7R, 50V, 10%, .033uF 191470-333
C302 0805, X7R, 50V, 0.1uF 133623-104
C303 0603, X7R, 50V, 10%, .033uF 191470-333
C304 0603, X7R, 50V, 10%, .033uF 191470-333
C305 C0G, 0603, 50V, 5%, 220pF 188454-221
C306 X7R, 0603, 16V, 5%, 4.7nF 257154-472J16
C307 C0G, 0603, 50V, 5%, 220pF 188454-221
C308 0603, X7R, 5%, 25V, 2.2nF 196999-222
