Bose PowerShare PS602P Service Manual

30
ELECTRICAL PART LIST
Capacitors (continued)
Amplifier PCB Assembly, PS602/PS602P/PS604
Reference
Designator
Description Part Numbe
r
Note
C309 0805, X7R, 50V, 0.1uF 133623-104
C310 0805, X7R, 10%, 25V, 1uF 181264-105
C311 C0G, 0603, 50V, 5%, 470pF 188454-471
C312 C0G, 0603, 50V, 5%, 47pF 188454-470
C313 0805, X7R, 10%, 25V, 1uF 181264-105
C314 0805, X7R, 10%, 25V, 1uF 181264-105
C315 0603, X7R, 5%, 25V, 4.7 nF 196999-472
C316 1411, TANT, 20V, 20%, 4.7uF 188588-475
C317 C0G, 0603, 50V, 5%, 4700pF 188454-472
C318 0603, C0G, SMD, 25V, 5%, 10nF 268368-103
C319 0805, X7R, 10%, 25V, 1uF 181264-105
C320 C0G, 0603, 50V, 5%, 470pF 188454-471
C321 0805, X7R, 10%, 25V, 1uF 181264-105
C322 0805, X7R, 10%, 25V, 1uF 181264-105
C323 0805, X7R, 10%, 25V, 1uF 181264-105
C324 X7R, 0603, 10%, 0.1uF, 50V 191470-104
C325 X7R, 0603, 25V, 5%, 220pF 196999-221
C326 X7R, 0603, 10%, 0.1uF, 50V 191470-104
C327 X7R, 0603, 10%, 0.1uF, 50V 191470-104
C328 X7R, 0603, 10%, 0.1uF, 50V 191470-104
C329 X7R, 0603, 16V, 5%, 47nF 257154-473J16
C330 0805, X7R, 10%, 25V, 1uF 181264-105
C331 X7R, 0603, 16V, 10%, 1uF 257154-105K16
C332 X7R, 0603, 16V, 5%, 47nF 257154-473J16
C333 X7R, 0603, 16V, 5%, 47nF 257154-473J16
C334 0805, X7R, 10%, 25V, 1uF 181264-105
C335 X7R, 0603, 16V, 10%, 1uF 257154-105K16
C336 X7R, 0603, 16V, 5%, 47nF 257154-473J16
C337 0805, X7R, 10%, 25V, 1uF 181264-105
C338 X7R, 0603, 16V, 10%, 1uF 257154-105K16
C339 0805, X7R, 10%, 25V, 1uF 181264-105
C340 X7R, 0603, 16V, 10%, 1uF 257154-105K16
C341 0603, X7R, 50V, 330pF 191470-331
C342 0603, X7R, 50V, 330pF 191470-331
C343 0603, X7R, 50V, 330pF 191470-331
C344 0603, X7R, 50V, 330pF 191470-331
C345 0805, C0G, 200V, 10%, 220pF 260668-221K
C346 0805, C0G, 200V, 10%, 220pF 260668-221K
C347 X7R, 1210, 200V, 10%, 220nF 327916-224K
C348 0805, C0G, 200V, 10%, 220pF 260668-221K
C349 X7R, 1210, 25V, 10%, 22uF, COMM 759068-226K1E
C350 0805, C0G, 200V, 10%, 220pF 260668-221K
C351 X7R, 1210, 200V, 10%, 220nF 327916-224K
C352 X7R, 1210, 200V, 10%, 220nF 327916-224K
C353 X7R, 0603, 10%, 0.1uF, 50V 191470-104
C354 X7R, 1210, 200V, 10%, 220nF 327916-224K
C355 C0G, 0603, 50V, 5%, 430pF 188454-431
C356 C0G, 0603, 50V, 5%, 430pF 188454-431
C357 C0G, 0603, 5%, 25V, 8.2nF 268368-822
C358 C0G, 0603, 50V, 5%, 430pF 188454-431
C359 X7R, 0603, 10%, 0.1uF, 50V 191470-104
C360 C0G, 1206, 100V, 5%, 0.047uF 354973-473J
