Bose PowerShare PS602P Service Manual

31
ELECTRICAL PART LIST
Capacitors (continued)
Amplifier PCB Assembly, PS602/PS602P/PS604
Reference
Designator
Description Part Numbe
r
Note
C361 X7R, 0603, 10%, 0.1uF, 50V 191470-104
C362 C0G, 0603, 50V, 5%, 1000pF 188454-102
C363 C0G, 0603, 50V, 5%, 200pF 188454-201
C364 C0G, 0603, 50V, 5%, 470pF 188454-471
C365 X7R, 0603, 10%, 0.1uF, 50V 191470-104
C366 C0G, 0603, 50V, 5%, 1200pF 188454-122
C367 X7R, 0603, 200V, 10%, 1000pF, COMM 718875-102K2D
C368 X7R, 0603, 100V, 10%, 1000pF, COMM 718875-102K2A
C369 0805, X7R, 50V, 0.1uF 133623-104
C370 0805, X7R, 50V, 0.1uF 133623-104
C371 FILM, 15mm LS, BULK, 10%, 250Vdc, 0.47uF 354214-474IKB
C373 X7R, 0603, 100V, 10%, 1000pF, COMM 718875-102K2A
C374 C0G, 1206, 100V, 5%, 0.047uF 354973-473J
C375 X7R, 0603, 100V, 10%, 1000pF, COMM 718875-102K2A
C377 X7R, 0603, 100V, 10%, 1000pF, COMM 718875-102K2A
C378 C0G, 0603, 50V, 5%, 430pF 188454-431
C400 X7R, 1210, 200V, 10%, 220nF 327916-224K
C401 X7R, 1210, 200V, 10%, 220nF 327916-224K
C402 C0G, 0603, 50V, 5%, 220pF 188454-221
C403 C0G, 0603, 50V, 5%, 220pF 188454-221
C404 X7R, 0603, 16V, 5%, 4.7nF 257154-472J16
C405 C0G, 0603, 50V, 5%, 470pF 188454-471
C406 C0G, 0603, 50V, 5%, 47pF 188454-470
C407 EL, SNAP-IN, DISK, 105C, 200V, 20%, 1500uF 629718-
152DDBW
C408 EL, SNAP-IN, DISK, 105C, 200V, 20%, 1500uF 629718-
152DDBW
C409 0603, X7R, 5%, 25V, 4.7nF 196999-472
C410 C0G, 0603, 50V, 5%, 4700pF 188454-472
C411 EL, SNAP-IN, DISK, 105C, 200V, 20%, 1500uF 629718-
152DDBW
C412 C0G, 0603, 50V, 5%, 470pF 188454-471
C413 0603, C0G, SMD, 25V, 5%, 10nF 268368-103
C414 X7R, 0603, 10%, 0.1uF, 50V 191470-104
C415 X7R, 1210, 200V, 10%, 220nF 327916-224K
C416 X7R, 1210, 200V, 10%, 220nF 327916-224K
C417 X7R, 1210, 200V, 10%, 220nF 327916-224K
C418 X7R, 1210, 200V, 10%, 220nF 327916-224K
C419 X7R, 1210, 200V, 10%, 220nF 327916-224K
C420 X7R, 1210, 200V, 10%, 220nF 327916-224K
C421 X7R, 1210, 200V, 10%, 220nF 327916-224K
C422 X7R, 0603, 16V, 5%, 47nF 257154-473J16
C423 0805, X7R, 10%, 25V, 1uF 181264-105
C424 X7R, 0603, 16V, 10%, 1uF 257154-105K16
C425 X7R, 0603, 16V, 5%, 47nF 257154-473J16
C426 X7R, 0603, 16V, 5%, 47nF 257154-473J16
C427 0805, X7R, 10%, 25V, 1uF 181264-105
C428 X7R, 0603, 16V, 10%, 1uF 257154-105K16
C429 X7R, 0603, 16V, 5%, 47nF 257154-473J16
C430 0805, X7R, 10%, 25V, 1uF 181264-105
C431 X7R, 0603, 16V, 10%, 1uF 257154-105K16
C432 0805, X7R, 10%, 25V, 1uF 181264-105
