Bose PowerShare PS602P Service Manual

52
ELECTRICAL PART LIST
Resistors (continued)
Rear Panel PCB Assembly, PS602P
Capacitors
Reference
Designator
Description
V
endor Part
Number
Note
R875 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R882 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R883 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R887 RCFA, 1/16W, 47RX4, 5%, 0603 4703-470J04
R888 RCFA, 1/16W, 47RX4, 5%, 0603 4703-470J04
R890 RMG, 1/16W, 0 OHM, 1%, 0603 4723-000A
R891 RMG, 1/16W, 0 OHM, 1%, 0603 4723-000A
R892 RMG, 1/16W, 0 OHM, 1%, 0603 4723-000A
R893 RMG, 1/16W, 0 OHM, 1%, 0603 4723-000A
R894 RMG, 1/16W, 0 OHM, 1%, 0603 4723-000A
Reference
Designator
Description
V
endor Part
Number
Note
C700 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C703 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C704 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C705 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C710 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C711 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C712 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C715 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C716 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C717 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C718 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C727 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C728 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C731 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103KAC
C732 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103KAC
C733 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103KAC
C734 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103KAC
C735 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103KAC
C736 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103KAC
C737 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103KAC
C738 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103KAC
C741 CC, 50V, 1000pF, 5%, 0603, X7R 150F-102JAC
C743 CC, 50V, 1000pF, 5%, 0603, X7R 150F-102JAC
C746 CC, 50V, 1000pF, 5%, 0603, X7R 150F-102JAC
C747 CC, 50V, 1000pF, 5%, 0603, X7R 150F-102JAC
C749 CC, 50V, 1000pF, 5%, 0603, X7R 150F-102JAC
C750 CC, 50V, 1000pF, 5%, 0603, X7R 150F-102JAC
C752 CC, 50V, 1000pF, 5%, 0603, X7R 150F-102JAC
C753 CC, 50V, 1000pF, 5%, 0603, X7R 150F-102JAC
C788 CC, 100V, 0.1uF, 10%, 1206, AVX 150H-104KCFD
C799 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C800 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C802 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C803 CC, 50V, 0.1uF, 10%, 0603X7R 150F-104KAC
C804 CC, 50V, 0.1uF, 10%, 0603X7R 150F-104KAC
C805 CC, 50V, 0.1uF, 10%, 0603X7R 150F-104KAC
C812 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C813 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
