ELECTRICAL PART LIST
Capacitors (continued)
Rear Panel PCB Assembly, PS602P
Diodes
Reference
Designator
Description
V
endor Part
Number
Note
D702 DIODE, BAV99, SOT23, PHILIPS 4840-8970
D703 DIODE, BAV99, SOT23, PHILIPS 4840-8970
D704 DIODE, BAV99, SOT23, PHILIPS 4840-8970
D705 DIODE, BAV99, SOT23, PHILIPS 4840-8970
D706 DIODE, BAV99, SOT23, PHILIPS 4840-8970
D707 DIODE, BAV99, SOT23, PHILIPS 4840-8970
D717 DIODE, BAV99, SOT23, PHILIPS 4840-8970
Reference
Designator
Description
V
endor Part
Number
Note
C814 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C815 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C816 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C817 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C831 CC, 50V, 100pF, 5%, 0603, C0G 150F-101JAC
C832 CC, 50V, 100pF, 5%, 0603, C0G 150F-101JAC
C833 CC, 50V, 100pF, 5%, 0603, C0G 150F-101JAC
C834 CC, 50V, 100pF, 5%, 0603, C0G 150F-101JAC
C846 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103KAC
C847 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103KAC
C848 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103KAC
C849 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103KAC
C850 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103KAC
C851 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103KAC
C856 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C857 CC, 6.3V, 22uF, 10%, 1206, 3.2X1.6 150B-226KCF
C859 CC, 16V, 0.1uF, 10%, 0603/1608, 1X2 150D-104KAC
C866 CC, 50V, 100pF, 5%, 0603, C0G 150F-101JAC
C867 CC, 50V, 100pF, 5%, 0603, C0G 150F-101JAC
C868 CC, 50V, 100pF, 5%, 0603, C0G 150F-101JAC
C869 CC, 50V, 100pF, 5%, 0603, C0G 150F-101JAC
C870 CC, 50V, 100pF, 5%, 0603, C0G 150F-101JAC
C871 CC, 50V, 100pF, 5%, 0603, C0G 150F-101JAC
C876 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C877 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C878 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C879 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
