Integrated Circuits
ELECTRICAL PART LIST
Rear Panel PCB Assembly, PS602P
Reference
Designator
Description
endor Part
Number
Note
U704 IC, NJM2068M-#ZZZB, DUAL, OP, AMP 3130-6890
U705 IC, NJM2068M-#ZZZB, DUAL, OP, AMP 3130-6890
U706 IC, NJM2068M-#ZZZB, DUAL, OP, AMP 3130-6890
U709 IC, NJM2068M-#ZZZB, DUAL, OP, AMP 3130-6890
U711 IC, 16-CH, DEMULTIPLEXER, 74HC4067M96,
SO24, TEXAS
3132-3021
U712 IC, 8BIT, SHIFT, REGISTER, 74HC166, SO-16 3132-3281
U715 IC, ANALOG-SW, DG211BDY-E3, SOIC-16 3133-0661
Miscellaneous
Reference
Designator
Description
endor Part
Number
Note
J701 SOCKET, M, 2P, P5, 300V, 15A, BLACK 2113-3361
J703 JACK, RCA, 2P, R/W, JK0200560N 2113-3109
J711B CONNECTOR, PIN, HEADER, 4P, P2.54, ST, F 2101-3294
J717 CONN, HEADER, 6P, P2.54, DIP, ST, M, L=8.54 2101-3393
J718 CONN, HEADER, 6P, P2.54, DIP, ST, M, L=8.54 2101-3393
J724 CONN, FFC, 20P, P0.5, SMT, ST, F 2101-3376
J725 CONN, FFC, 20P, P0.5, SMT, ST, F 2101-3376
J726 JACK, COMBO, NCJ10FI-V-0, NEUTRIK 2113-3046
J727 JACK, COMBO, NCJ10FI-V-0, NEUTRIK 2113-3046
J728 SHEET, GROUND, BRASS, T=0.8, TIN, PLATED,
MINI2
4136-0991
J742 CONN, HEADER, 5P, P2.54, DIP, ST, M, L=11.08 2101-3409
J743 CONN, HEADER, 5P, P2.54, DIP, ST, M, L=11.08 2101-3409
