ELECTRICAL PART LIST
Capacitors (continued)
DSP PCB Assembly, PS602
Reference
Designator
Description
V
endor Part
Number
Note
C500 CC, 50V, 22pF, 5%, 0603, C0G 150F-220JAC
C501 CC, 50V, 22pF, 5%, 0603, C0G 150F-220JAC
C502 CC, 50V, 22pF, 5%, 0603, C0G 150F-220JAC
C503 CC, 50V, 100pF, 5%, 0603, C0G 150F-101JAC
C504 CC, 50V, 100pF, 5%, 0603, C0G 150F-101JAC
C507 CC, 50V, 100pF, 5%, 0603, C0G 150F-101JAC
C508 CC, 50V, 100pF, 5%, 0603, C0G 150F-101JAC
C509 CC, 50V, 5600pF, 10%, 0603, X7R 150F-562KAC
C510 CC, 50V, 150pF, 5%, 0603, C0G 150F-151JAC
C511 CC, 50V, 100pF, 5%, 0603, C0G 150F-101JAC
C512 CC, 50V, 100pF, 5%, 0603, C0G 150F-101JAC
C518 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C519 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C526 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C527 CT, 6.3V, 47uF, 10%, SMD, 85C, 1.6X3.2 154B-476KCF
C531 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C532 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C533 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C534 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C535 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C539 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C540 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C541 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C542 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C543 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C544 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C547 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C548 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C549 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C550 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C556 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C557 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C558 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C559 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C560 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C562 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C564 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C567 CC, 50V, 1uF, 10%, 0805 150F-105KBD
C570 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C571 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C572 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C573 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C578 CC, 50V, 100pF, 5%, 0603, C0G 150F-101JAC
C580 CC, 50V, 2700pF, 10%, 0603, X7R 150F-272KAC
C581 CC, 50V, 100pF, 5%, 0603, C0G 150F-101JAC
C582 CC, 50V, 100pF, 5%, 0603, C0G 150F-101JAC
C584 CC, 50V, 2700pF, 10%, 0603, X7R 150F-272KAC
C585 CC, 50V, 100pF, 5%, 0603, C0G 150F-101JAC
C595 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C596 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C597 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103KAC
C598 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103KAC
