Bose PowerShare PS602P Service Manual

67
ELECTRICAL PART LIST
Capacitors (continued)
DSP PCB Assembly, PS602
Inductors
Reference
Designator
Description
V
endor Part
Number
Note
L400 INDUCTOR, 22UH, 20%, 8.1X8, B1000AS-220M=P3,
SMD, TOKO
1803-0103
L401 FERRITE, BEAD, CHIP, SEBW201209U121MT, 0805 1808-0872
L402 FERRITE, BEAD, CHIP, SEBW201209U121MT, 0805 1808-0872
L403 FERRITE, BEAD, CHIP, SEBW201209U121MT, 0805 1808-0872
L404 FERRITE, BEAD, CHIP, SEBW201209U121MT, 0805 1808-0872
L405 FERRITE, BEAD, CHIP, SEBW201209U121MT, 0805 1808-0872
L406 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878
L407 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878
L408 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878
L409 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878
L410 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878
L411 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878
L412 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878
L413 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878
L414 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878
L415 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878
Diodes
Reference
Designator
Description
V
endor Part
Number
Note
D400 DIODE, SCHOTTKY, SK16, DO-214AA, 60V, 1A,
SMD, PANJIT
480S-K160
D401 DIODE, SCHOTTKY, SK16, DO-214AA, 60V, 1A,
SMD, PANJIT
480S-K160
D402 LED, SMD, 2.0X1.25X0.8, GN, SUPER, EVLITE 3700-7839
D403 LED, SMD, 2.0X1.25X0.8, RD, SUPER, EVLITE 3700-7839
D404 DIODE, BAV99, SOT23, PHILIPS 4840-8970
D405 DIODE, BAV99, SOT23, PHILIPS 4840-8970
D406 LED, SMD, 2.0X1.25X0.8, GN, SUPER, EVLITE 3700-7839
D407 DIODE, BAV99, SOT23, PHILIPS 4840-8970
D408 LED, SMD, 2.0X1.25X0.8, RD, SUPER, EVLITE 3700-7839
D410 DIODE, 1SS355TE-17, ROHM 4840-1660
D415 DOUBLE, DIODE, BAT54S, SOT-23, SCHOTTKY,
SMD
480T-54S0
D416 DOUBLE, DIODE, BAT54S, SOT-23, SCHOTTKY,
SMD
480T-54S0
D417 DOUBLE, DIODE, BAT54S, SOT-23, SCHOTTKY,
SMD
480T-54S0
D418 DOUBLE, DIODE, BAT54S, SOT-23, SCHOTTKY,
SMD
480T-54S0
Reference
Designator
Description
V
endor Part
Number
Note
C599 CC, 50V, 1uF, 10%, 0805 150F-105KBD
C600 CC, 100V, 0.1uF, 10%, 0805, X7R 150H-104KBD
C601 CC, 16V, 1uF, 10%, 0603, 0.8X1.6 150D-105KAC
C602 CC, 16V, 1uF, 10%, 0603, 0.8X1.6 150D-105KAC
