Bose PowerShare PS602P Service Manual

68
ELECTRICAL PART LIST
Transistors
DSP PCB Assembly, PS602
Reference
Designator
Description
V
endor Part
Number
Note
Q409 TR, KTA1504Y 4851-504Y
Q410 TR, PNP, 2SA2058, HFE:, 1252-3S1A, SM 4852-0580
Integrated Circuits
Miscellaneous
Reference
Designator
Description
V
endor Part
Number
Note
J400 WAFER, 10, PIN, P2 2102-100S
J401 12P, ST.WAFER, P=2.5, COULOMB 2102-121S
J403 CONN, FFC, 10P, P0.5, SMT, ST, F 2101-3375
J405 CONN, FFC, 20P, P0.5, SMT, ST, F 2101-3376
J406 CONN, FFC, 20P, P0.5, SMT, ST, F 2101-3376
J408 CONN, FFC, 20P, P0.5, SMT, ST, F 2101-3376
J409 CONN, HEADER, 7P, P2.54, ST, M, SINGLE, BODY 2101-3297
X400 CRYSTAL, HC49, 12.288MHZ, 20PPM, 4.7X13, SMD 2300-3284
X401 CRYSTAL, 12MHZ, -40C, SMD 2300-2430
Reference
Designator
Description
V
endor Part
Number
Note
U400 IC, MCU, LPC11U35FBD48, LQFP48 3132-9481
U401 IC, FLASH, MX25L4006EM1, 8-SOP 3132-8711
U402 IC, DSP, ADAU1450W, LFCSP72 3132-9471
U403 IC, REG, NCP1117ST33T3G, 3.3V, SOT-223,
ONSEMI
3132-148111
U404 IC, 16-CH, DEMULTIPLEXER, 74HC4067M96, SO24,
TEXAS
3132-3021
U406 IC, SETP-DOWN, CONVERTER, MP1591DN,
SOIC8N, MPS
3132-4711
U407 IC, ASIC, SN74LVC2G17, DCK 3132-7450
U408 IC, REGULATOR, 7815, DPAK/TO-252, AUK 3132-816149
U410 IC, NJM2068M-#ZZZB, DUAL, OP, AMP 3130-6890
U411 IC, NJM2068M-#ZZZB, DUAL, OP, AMP 3130-6890
U415 IC, EXTEND, 74HC4094, SO16 3132-4431
U416 IC, REGULATOR, -15V, 7915, DPAK/TO-252, AUK 3132-817149
U419 IC, CODEC, CS4272-CZZ, 28PIN, TSSOP, CIRRUS
LOGIC
3132-4471
U421 IC, NJM2068M-#ZZZB, DUAL, OP, AMP 3130-6890
U422 IC, NJM2068M-#ZZZB, DUAL, OP, AMP 3130-6890
U425 IC, NJM2068M-#ZZZB, DUAL, OP, AMP 3130-6890
U426 IC, REGULATOR, TL432BIDBZR, SOT-23-3, TI 3132-769116
