Bose PowerShare PS602P Service Manual

71
ELECTRICAL PART LIST
Resistors (continued)
DSP PCB Assembly, PS602P
Reference
Designator
Description
V
endor Part
Number
Note
R544 RCFA, 1/16W, 47RX4, 5%, 0603 4703-470J+P-04
R545 RCFA, 1/16W, 47RX4, 5%, 0603 4703-470J+P-04
R547 RCFA, 1/16W, 47RX4, 5%, 0603 4703-470J+P-04
R548 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R549 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R551 RMG, 1/10W, 301 OHM, 1%, 0805 4720-3010+J
R552 RMG, 1/10W, 301 OHM, 1%, 0805 4720-3010+J
R554 RMG, 1/16W, 0 OHM, 1%, 0603 4723-000A+P
R556 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R557 RMG, 1/16W, 1.78K, 1%, 0603 4723-1781+P
R558 RMG, 1/16W, 806 OHM, 1%, 0603 4723-806R+P
R559 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R560 RMG, 1/16W, 806 OHM, 1%, 0603 4723-806R+P
R561 RMG, 1/16W, 806 OHM, 1%, 0603 4723-806R+P
R562 RMG, 1/16W, 806 OHM, 1%, 0603 4723-806R+P
R564 RMG, 1/16W, 100 OHM, 1%, 0603 4723-101A+P
R567 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R568 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R569 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R570 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R571 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R572 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R573 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R574 RMG, 1/16W, 100K, 1%, 0603 4723-104A+P-R
R575 RMG, 1/16W, 100K, 1%, 0603 4723-104A+P-R
R576 RMG, 1/16W, 100K, 1%, 0603 4723-104A+P-R
R577 RMG, 1/16W, 100K, 1%, 0603 4723-104A+P-R
R583 RMG, 1/16W, 100K, 1%, 0603 4723-104A+P-R
R584 RMG, 1/16W, 100K, 1%, 0603 4723-104A+P-R
R585 RMG, 1/16W, 100K, 1%, 0603 4723-104A+P-R
R586 RMG, 1/16W, 100K, 1%, 0603 4723-104A+P-R
R599 RMG, 1/16W, 1M, 1%, 0603 4723-105A+P
R602 RMG, 1/16W, 33 OHM, 1%, 0603 4723-330A+P
R604 RMG, 1/16W, 0 OHM, 1%, 0603 4723-000A+P
R605 RMG, 1/16W, 220 OHM, 1%, 0603/1608 4723-221A+P
R606 RMG, 1/16W, 220 OHM, 1%, 0603/1608 4723-221A+P
R611 RMG, 1/16W, 1.5K, 1%, 0603 4723-152A+P-R
R612 RMG, 1/16W, 2.2K, 1%, 0603/1608 4723-222A+P
R613 RMG, 1/16W, 2.2K, 1%, 0603/1608 4723-222A+P
R614 RMG, 1/10W, 47K, 1%, 0805 4720-473A+J
R615 RMG, 1/16W, 22K, 1%, 0603 4723-223A+P-R
R616 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A+P
R617 RMG, 1/16W, 22 OHM, 5%, 0603 4723-220J+P-R
R618 RMG, 1/16W, 22 OHM, 5%, 0603 4723-220J+P-R
R621 RMG, 1/16W, 4.99K, 1%, 0603 4723-4991+P
R622 RMG, 1/16W, 4.99K, 1%, 0603 4723-4991+P
R623 RMG, 1/16W, 4.99K, 1%, 0603 4723-4991+P
R624 RMG, 1/16W, 4.99K, 1%, 0603 4723-4991+P
R629 RMG, 1/16W, 4.99K, 1%, 0603 4723-4991+P
R630 RMG, 1/16W, 4.99K, 1%, 0603 4723-4991+P
R631 RMG, 1/16W, 4.99K, 1%, 0603 4723-4991+P
R632 RMG, 1/16W, 4.99K, 1%, 0603 4723-4991+P
