Bose PowerShare PS602P Service Manual

72
ELECTRICAL PART LIST
Resistors (continued)
DSP PCB Assembly, PS602P
Capacitors
Reference
Designator
Description
V
endor Part
Number
Note
R633 RMG, 1/16W, 4.99K, 1%, 0603 4723-4991+P
R634 RMG, 1/16W, 4.99K, 1%, 0603 4723-4991+P
R635 RMG, 1/16W, 4.99K, 1%, 0603 4723-4991+P
R636 RMG, 1/16W, 4.99K, 1%, 0603 4723-4991+P
R645 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R651 RMG, 1/16W, 5.6K, 1%, 0603/1608 4723-562A+P
R652 RMG, 1/16W, 0 OHM, 1%, 0603 4723-000A+P
R653 RMG, 1/16W, 0 OHM, 1%, 0603 4723-000A+P
R654 RMG, 1/16W, 0 OHM, 1%, 0603 4723-000A+P
R655 RMG, 1/16W, 0 OHM, 1%, 0603 4723-000A+P
Reference
Designator
Description
V
endor Part
Number
Note
C400 CC, 6.3V, 22uF, 10%, 1206, 3.2X1.6 150B-226K+6-CF
C401 CC, 6.3V, 22uF, 10%, 1206, 3.2X1.6 150B-226K+6-CF
C402 CC, 50V, 1000pF, 5%, 0603, X7R 150F-102J+P-AC
C403 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C404 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C405 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C406 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C407 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C408 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C409 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C410 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C412 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C413 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C414 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C415 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C416 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C417 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C418 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C419 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C421 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C422 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C423 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C425 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C426 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C427 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C428 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C429 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C430 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C431 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C432 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C433 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C434 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C435 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C436 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C437 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C438 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C439 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C440 CE, 25V, 100uF, 20%, 6.3X7.7, SMD 157E-107M+3-LO
