Bose PowerShare PS602P Service Manual

73
ELECTRICAL PART LIST
Capacitors (continued)
DSP PCB Assembly, PS602P
Reference
Designator
Description
V
endor Part
Number
Note
C441 CE, 25V, 100uF, 20%, 6.3X7.7, SMD 157E-107M+3-LO
C442 CC, 25V, 10uF, 10%, 1206, 3.2X1.6, X5R 150E-106K+6-CF
C443 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C444 CC, 50V, 0.01uF, 5%, 0603 150F-103J+P-AC
C445 CC, 50V, 0.01uF, 5%, 0603 150F-103J+P-AC
C446 CT, 16V, 10uF, 20%, SMD, 1.6X3.2 154D-106M+3-CF
C447 CT, 25V, 3.3uF, 20%, SM, 2.8X3.5 154E-335M+3-EF
C448 CT, 16V, 47uF, 10%, SMD, 85C, 6.0X3.2 154D-476K+3-KF
C449 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C450 CE, 25V, 220uF, 20%, SM, 8.4X10, LOW, ESR 157E-227M+3-PSR5
C451 CC, 16V, 1uF, 10%, 0603, 0.8X1.6 150D-105K+P-AC
C452 CC, 50V, 22pF, 5%, 0603, C0G 150F-220J+P-AC
C453 CC, 50V, 22pF, 5%, 0603, C0G 150F-220J+P-AC
C454 CE, 35V, 47uF, 20%, SM, 6.6X5.7, LOW, ESR 157Q-476M+3-MKR5
C455 CE, 35V, 47uF, 20%, SM, 6.6X5.7, LOW, ESR 157Q-476M+3-MKR5
C456 CC, 50V, 1uF, 10%, 0805 150F-105K+J-BD
C458 CT, 35V, 4.7uF, 20%, SMD, 3.5X2.8 154Q-475M+3-FE
C459 CC, 50V, 2700pF, 10%, 0603, X7R 150F-272K+P-AC
C460 CC, 50V, 10pF, 5%, 0603, C0G 150F-100J+P-AC
C461 CC, 50V, 10pF, 5%, 0603, C0G 150F-100J+P-AC
C462 CC, 50V, 10pF, 5%, 0603, C0G 150F-100J+P-AC
C463 CC, 50V, 10pF, 5%, 0603, C0G 150F-100J+P-AC
C468 CT, 6.3V, 100uF, 20%, SMD, 3.5X2.8MM 154B-107M+3-FE
C469 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103K+P-AC
C470 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103K+P-AC
C471 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103K+P-AC
C472 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103K+P-AC
C473 CC, 16V, 1uF, 10%, 0603, 0.8X1.6 150D-105K+P-AC
C474 CC, 16V, 1uF, 10%, 0603, 0.8X1.6 150D-105K+P-AC
C475 CC, 16V, 1uF, 10%, 0603, 0.8X1.6 150D-105K+P-AC
C476 CC, 16V, 1uF, 10%, 0603, 0.8X1.6 150D-105K+P-AC
C477 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C478 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C479 CT, 10V, 10uF, 20%, SM, 1.6X3.2 154C-106M+3-CF
C480 CC, 50V, 1uF, 10%, 0805 150F-105K+J-BD
C481 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C482 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C483 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C484 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C485 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C490 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C491 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C492 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C493 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C498 CE, 6.3V, 100uF, 20%, SM, 06.3, L5.4 157B-107M+3-LJ
C499 CC, 50V, 22pF, 5%, 0603, C0G 150F-220J+P-AC
C500 CC, 50V, 22pF, 5%, 0603, C0G 150F-220J+P-AC
C501 CC, 50V, 22pF, 5%, 0603, C0G 150F-220J+P-AC
C502 CC, 50V, 22pF, 5%, 0603, C0G 150F-220J+P-AC
C503 CC, 50V, 100pF, 5%, 0603, C0G 150F-101J+P-AC
C504 CC, 50V, 100pF, 5%, 0603, C0G 150F-101J+P-AC
C507 CC, 50V, 100pF, 5%, 0603, C0G 150F-101J+P-AC
