ELECTRICAL PART LIST
Capacitors (continued)
DSP PCB Assembly, PS602P
Reference
Designator
Description
V
endor Part
Number
Note
C508 CC, 50V, 100pF, 5%, 0603, C0G 150F-101J+P-AC
C509 CC, 50V, 5600pF, 10%, 0603, X7R 150F-562K+P-AC
C510 CC, 50V, 150pF, 5%, 0603, C0G 150F-151J+P-AC
C511 CC, 50V, 100pF, 5%, 0603, C0G 150F-101J+P-AC
C512 CC, 50V, 100pF, 5%, 0603, C0G 150F-101J+P-AC
C518 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C519 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C526 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C527 CT, 6.3V, 47uF, 10%, SMD, 85C, 1.6X3.2 154B-476K+3-CF
C531 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C532 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C533 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C534 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C535 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C539 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C540 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C541 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C542 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C543 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C544 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C545 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C546 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C547 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C548 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C549 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C550 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C556 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C557 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C558 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C559 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C560 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C562 CC, 50V, 0.1uF, 5%, 0603 150F-104J+P-AC
C564 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C567 CC, 50V, 1U, 10%, 0805 150F-105K+J-BD
C570 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C571 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C572 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C573 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C578 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C580 CC, 50V, 2700pF, 10%, 0603, X7R 150F-272K+P-AC
C581 CC, 50V, 100pF, 5%, 0603, C0G 150F-101J+P-AC
C582 CC, 50V, 100pF, 5%, 0603, C0G 150F-101J+P-AC
C584 CC, 50V, 2700pF, 10%, 0603, X7R 150F-272K+P-AC
C585 CC, 50V, 100pF, 5%, 0603, C0G 150F-101J+P-AC
C595 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C596 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C597 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103K+P-AC
C598 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103K+P-AC
C601 CC, 16V, 1uF, 10%, 0603, 0.8X1.6 150D-105K+P-AC
C602 CC, 16V, 1uF, 10%, 0603, 0.8X1.6 150D-105K+P-AC
