Bose PowerShare PS602P Service Manual

84
ELECTRICAL PART LIST
Capacitors (continued)
DSP PCB Assembly, PS604
Inductors
Reference
Designator
Description
V
endo
r
Part
Number
Note
L400 INDUCTOR, 22UH, 20%, 8.1X8, B1000AS-220M=P3,
SMD, TOKO
1803-0103
L401 FERRITE, BEAD, CHIP, SEBW201209U121MT, 0805 1808-0872
L402 FERRITE, BEAD, CHIP, SEBW201209U121MT, 0805 1808-0872
L403 FERRITE, BEAD, CHIP, SEBW201209U121MT, 0805 1808-0872
L404 FERRITE, BEAD, CHIP, SEBW201209U121MT, 0805 1808-0872
L405 FERRITE, BEAD, CHIP, SEBW201209U121MT, 0805 1808-0872
L406 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878
L407 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878
L408 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878
Reference
Designator
Description
V
endor Part
Number
Note
C559 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C560 CE, 16V, 10uF, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C561 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C562 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C563 CC, 50V, 1uF, 10%, 0805 150F-105KBD
C564 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C565 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C567 CC, 50V, 1uF, 10%, 0805 150F-105KBD
C570 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C571 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C572 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C573 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C574 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C575 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C576 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C577 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C578 CC, 50V, 100pF, 5%, 0603, C0G 150F-101JAC
C580 CC, 50V, 2700pF, 10%, 0603, X7R 150F-272KAC
C581 CC, 50V, 100pF, 5%, 0603, C0G 150F-101JAC
C582 CC, 50V, 100pF, 5%, 0603, C0G 150F-101JAC
C584 CC, 50V, 2700pF, 10%, 0603, X7R 150F-272KAC
C585 CC, 50V, 100pF, 5%, 0603, C0G 150F-101JAC
C586 CC, 50V, 100pF, 5%, 0603, C0G 150F-101JAC
C587 CC, 50V, 100pF, 5%, 0603, C0G 150F-101JAC
C588 CC, 50V, 2700pF, 10%, 0603, X7R 150F-272KAC
C590 CC, 50V, 100pF, 5%, 0603, C0G 150F-101JAC
C592 CC, 50V, 2700pF, 10%, 0603, X7R 150F-272KAC
C593 CC, 50V, 100pF, 5%, 0603, C0G 150F-101JAC
C595 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C596 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C597 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103KAC
C598 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103KAC
C599 CC, 50V, 1uF, 10%, 0805 150F-105KBD
C600 CC, 100V, 0.1uF, 10%, 0805, X7R 150H-104KBD
C601 CC, 16V, 1uF, 10%, 0603, 0.8X1.6 150D-105KAC
C602 CC, 16V, 1uF, 10%, 0603, 0.8X1.6 150D-105KAC
C603 CC, 16V, 1uF, 10%, 0603, 0.8X1.6 150D-105KAC
C604 CC, 16V, 1uF, 10%, 0603, 0.8X1.6 150D-105KAC
