Bose PowerShare PS602P Service Manual

85
Reference
Designator
Description
V
endo
r
Part
Number
Note
L409 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878
L410 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878
L411 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878
L412 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878
L413 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878
L414 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878
L415 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878
L416 FERRITE, CHIP, 0603, BLM18AG102SN1D 1808-0878
ELECTRICAL PART LIST
Inductors (continued)
DSP PCB Assembly, PS604
Diodes
Reference
Designator
Description
V
endor Part
Number
Note
D400 DIODE, SCHOTTKY, SK16, DO-214AA, 60V, 1A, SMD,
PANJIT
480S-K160
D401 DIODE, SCHOTTKY, SK16, DO-214AA, 60V, 1A, SMD,
PANJIT
480S-K160
D402 LED, SMD, 2.0X1.25X0.8, GN, SUPER, EVLITE 3700-7839
D403 LED, SMD, 2.0X1.25X0.8, RD, SUPER, EVLITE 3700-7839
D404 DIODE, BAV99, SOT23, PHILIPS 4840-8970
D405 DIODE, BAV99, SOT23, PHILIPS 4840-8970
D406 LED, SMD, 2.0X1.25X0.8, GN, SUPER, EVLITE 3700-7839
D407 DIODE, BAV99, SOT23, PHILIPS 4840-8970
D408 LED, SMD, 2.0X1.25X0.8, RD, SUPER, EVLITE 3700-7839
D410 DIODE, 1SS355TE-17, ROHM 4840-1660
D411 DOUBLE DIODE, BAT54S, SOT-23, SCHOTTKY, SMD 480T-54S0
D412 DOUBLE DIODE, BAT54S, SOT-23, SCHOTTKY, SMD 480T-54S0
D413 DOUBLE DIODE, BAT54S, SOT-23, SCHOTTKY, SMD 480T-54S0
D414 DOUBLE DIODE, BAT54S, SOT-23, SCHOTTKY, SMD 480T-54S0
D415 DOUBLE DIODE, BAT54S, SOT-23, SCHOTTKY, SMD 480T-54S0
D416 DOUBLE DIODE, BAT54S, SOT-23, SCHOTTKY, SMD 480T-54S0
D417 DOUBLE DIODE, BAT54S, SOT-23, SCHOTTKY, SMD 480T-54S0
D418 DOUBLE DIODE, BAT54S, SOT-23, SCHOTTKY, SMD 480T-54S0
Reference
Designator
Description
V
endo
r
Part
Number
Note
Q409 TR, KTA1504Y 4851-504Y
Q410 TR, PNP, 2SA2058, HFE:, 1252-3S1A, SM 4852-0580
Diodes
Integrated Circuits
Reference
Designator
Description
V
endor Part
Number
Note
U400 IC, MCU, LPC11U35FBD48, LQFP48 3132-9481
U401 IC, FLASH, MX25L4006EM1, 8-SOP 3132-8711
U402 IC, DSP, ADAU1450W, LFCSP72 3132-9471
U403 IC, REG, NCP1117ST33T3G, 3.3V, SOT-223, ONSEMI 3132-148111
U404 IC, 16-CH, DEMULTIPLEXER, 74HC4067M96, SO24,
TEXAS
3132-3021
U406 IC, SETP-DOWN, CONVERTER, MP1591DN, SOIC8N,
MPS
3132-4711
U407 IC, ASIC, SN74LVC2G17, DCK 3132-7450
U408 IC, REGULATOR, 7815, DPAK/TO-252, AUK 3132-816149
