Bose PowerShare PS602P Service Manual

86
ELECTRICAL PART LIST
Integrated Circuits (continued)
DSP PCB Assembly, PS604
Miscellaneous
Reference
Designator
Description
V
endo
r
Part
Number
Note
J400 WAFER, 10, PIN, P2 2102-100S
J401 12P, ST.WAFER, P=2.5, COULOMB 2102-121S
J403 CONN, FFC, 10P, P0.5, SMT, ST, F 2101-3375
J404 CONN, FFC, 10P, P0.5, SMT, ST, F 2101-3375
J405 CONN, FFC, 20P, P0.5, SMT, ST, F 2101-3376
J406 CONN, FFC, 20P, P0.5, SMT, ST, F 2101-3376
J407 CONN, FFC, 20P, P0.5, SMT, ST, F 2101-3376
J408 CONN, FFC, 20P, P0.5, SMT, ST, F 2101-3376
J409 CONNECTOR, HEADER, 7P, P2.54, ST, M, SINGLE,
BODY
2101-3297
X400 CRYSTAL, HC49, 12.288MHZ20PPM, 4.7X13, SMD 2300-3284
X401 CRYSTAL, 12MHZ, -40, C, SMD 2300-2430
Reference
Designator
Description
V
endor Part
Number
Note
U410 IC, NJM2068M-#ZZZB, DUAL, OP, AMP 3130-6890
U411 IC, NJM2068M-#ZZZB, DUAL, OP, AMP 3130-6890
U412 IC, NJM2068M-#ZZZB, DUAL, OP, AMP 3130-6890
U414 IC, NJM2068M-#ZZZB, DUAL, OP, AMP 3130-6890
U415 IC, EXTEND, 74HC4094, SO16 3132-4431
U416 IC, REGULATOR, -15V, 7915, DPAK/TO-252, AUK 3132-817149
U419 IC, CODEC, CS4272-CZZ, 28PIN, TSSOP, CIRRUS
LOGIC
3132-4471
U420 IC, CODEC, CS4272-CZZ, 28PIN, TSSOP, CIRRUS
LOGIC
3132-4471
U421 IC, NJM2068M-#ZZZB, DUAL, OP, AMP 3130-6890
U422 IC, NJM2068M-#ZZZB, DUAL, OP, AMP 3130-6890
U423 IC, NJM2068M-#ZZZB, DUAL, OP, AMP 3130-6890
U424 IC, NJM2068M-#ZZZB, DUAL, OP, AMP 3130-6890
U425 IC, NJM2068M-#ZZZB, DUAL, OP, AMP 3130-6890
U426 IC, REGULATOR, TL432BIDBZR, SOT-23-3, TI 3132-769116
