Precision™ Spinal Cord Stimulator System Clinician Manual
Clinician Manual
97035873-01 22 of 75
Fully Assembled Entrada Needle
Components
Components are marked with dots to indicate use order, and the dots should be in the same direction when
assembling the needle.
Needle Stylet, •
Loss of Resistance (LOR) adaptor, ••
Slotted Needle, •••
Peelable Sheath
Note: Do not mix components between Entrada 4.5 in and 6.0 in needles. Needles are clearly labeled
with needle lengths and are also color coded (as they appear on the product, green=6.0 in and
blue=4.5 in).
Assembling and Reassembling the Entrada Needle
CAUTION: Do not insert or reinsert the needle stylet, LOR adaptor, or slotted needle into the sheath while
the sheath is inserted within the patient.
1. Insert the slotted needle into the sheath.
2. Insert the LOR adaptor into the slotted needle.
3. Insert the needle stylet into LOR adaptor and advance forward until fully seated into needle assembly.
