11 Technical specifications
108 ARC 300 / ARC 350 Operating manual 900-350_IFU_V2.6_10296-S13-20100111-EN
Setting Program
Bipolar TUR CUT 18-20 (only Socket 3)
P [W]
ARC350BTUR_SE_080125_1
0
50
100
150
200
250
300
350
400
450
10 100 1000 10000
Effekt 9
Effekt 8
Effekt 7
Effekt 6
Effekt 5
Effekt 4
Effekt 3
Effekt 2
Effekt 1
Effekt 0
Measurement of resistances
• Diagram of the power output P [W] as a
function of the load resistance R [Ω] for
the “Bipolar TUR CUT” “Effect 0-9”
• HF output voltage U [Vp] as a function
of the “Bipolar TUR CUT”
"Effect 0-9” setting (idle mode)
Setting Program
Bipolar TUR COAG 18-20 (only Socket 3)
0
50
100
150
200
250
10 100 1000 10000
P [W]
ARC350BTURC_SE_080125_1
Effekt 7-9
Effekt 6
Effekt 5
Effekt 4
Effekt 3
Effekt 2
Effekt 1
Effekt 0
Measurement of resistances
• Diagram of the power output P [W] as a
function of the load resistance R [Ω] for
the “Bipolar TUR COAG” “Effect 0-9”
• HF output voltage U [Vp] as a function
of the “Bipolar TUR COAG” “Effect”
setting (idle mode)
