3 Functionality
900-350_IFU_V2.6_10296-S13-20100111-EN ARC 300 / ARC 350 Operating manual 31
3.8. Foot switch
In addition to the manual switch, the foot switch can be used to activate
various operating modes.
The foot switches can be connected either to connection socket 50 or
52. The HF device automatically detects whether a foot switch is
connected or not.
The following foot switch systems can be connected to the HF device:
Article No. Designation
901-011 Single-pedal foot switch (SP)
Single-pedal foot switch with
pushbutton (SP+)
901-021 Double-pedal foot switch (DP)
901-031 Double-pedal foot switch with sensor
(DP+)
Pos: 23 /679-BOWA/ARC 300/35 0/4 Funktionsweise/ 4.9 Speicherfunktio nen @ 4\mod_1261040500 460_6.doc @ 34786 @ 2
3.9. Memory functions
For generators from the ARC series, the parameter settings of all
programs can be stored.
To do this, set parameters such as output, blend factor, coagulation
mode and foot switch assignment and then store them by pressing the
AUTOSTART 32 key and keeping it pressed. This storage procedure
only stores the current program.
By pressing a key you can call up the individual device settings and the
entered empirical values; see Chapter "Basic Settings", Page 41.
The saved values will be stored even when the device is switched off.
Pos: 24 /679-BOWA/ARC 300/35 0/5 Beschreibung/5 Besc hreibung @ 4\mod_1261 040517772_6.doc @ 34805 @ 1
