11 Technical specifications
74 ARC 300 / ARC 350 Operating manual 900-350_IFU_V2.6_10296-S13-20100111-EN
11. Technical specifications
Pos: 50 /679-BOWA/ARC 300/35 0/12 Technische Dat en/12.1 Technische Merk male @ 4\mod_126104072356 9_6.doc @ 35318 @ 2
11.1. Technical specifications for the HF devices
ARC 300 and ARC 350
Insulation type / Classification
EMC IEC 60601-1-2
Level of protection provided by the housing IP 21
Protection class according to EN 60601-1 I
Type of application component as specified in
EN 60601-1
CF
Compliance with standards IEC 60601-1: 1988,
IEC 60601-1-A1: 1991,
IEC 60601-1-A2: 1995,
IEC 60529:1989+A1:1999,
IEC 60601-1-1: 2000 (in
combination with ARC PLUS)
IEC 60601-1-2: 2001,
IEC 60601-1-4: 2000,
IEC 60601-2-2: 1998,
IEC 61000-3-2: 2001,
ISO 14971: 2000
Classification as per EC Directive 93/42/EEC IIb
Power connection
Power consumption in standby mode 25 VA
Line frequency 50/60 Hz
Max. power consumption with an HF power output
of 300 W
500 VA
Connection for potential equalization line Yes
Voltage range: 230 V
Input voltage range 198 V to 260 V
Current consumption in standby mode 110 mA
Current consumption at max. HF output 3.2 A
Mains fuses 2 x 4 A slow-blow
Voltage range: 100 V
Input voltage range 90 V to 110 V
Current consumption in standby mode 220 mA
Current consumption at max. HF output 6.4 A
Mains fuses 2 x 8 A slow-blow
Voltage range: 115 V
Input voltage range 100 V to 130 V
Current consumption in standby mode 220 mA
Current consumption at max. HF output 6.4 A
Mains fuses 2 x 8 A slow-blow
