5 Preparation
900-350_IFU_V2.6_10296-S13-20100111-EN ARC 300 / ARC 350 Operating manual 39
5.4. Function test
5.4.1. Automatic test functions
The HF device automatically carries out a self-test after being switched
on and a cyclical test during operation. If errors occur, see Chapter
Detecting and correcting errors, Page 64.
5.4.2. EASY neutral electrode monitoring
(EASY monitoring)
NOTE
Incorrect application of the neutral electrode!
X Ensure that the specifications for the correct application of the
neutral electrode with regard to size, adhesive properties and full-
surface contact of the complete electrode have been met.
The following functions can be tested for the split and solid neutral
electrodes:
Actual status Output Measure
Cable for solid/split neutral electrode
not connected
Indicators for EASY monitoring of
split neutral electrode 20 or EASY
monitoring of solid neutral electrode
19 do not light up
X Plug in the cable for the
solid/split neutral electrode.
Only the cable for solid/split neutral
electrode is connected
Indicators for EASY monitoring of
split neutral electrode 20 or EASY
monitoring of solid neutral electrode
19 light up
X Check the cable for a short
circuit.
Cable with split neutral electrode
plugged in and not attached to
patient.
Indicators for EASY monitoring of
split neutral electrode 20 or EASY
monitoring of solid neutral electrode
19 light up
X Check whether the electrode is
correctly attached to the cable
connection.
The cable for the split or solid neutral
electrode is plugged in and attached
to the patient.
The indicators for EASY monitoring
of the split neutral electrode 20 or
EASY monitoring of the solid neutral
electrode 19 light up green, but the
type of neutral electrode is not
correctly detected.
X Based on the assessment of
benefit and harm, decide
whether you should activate the
HF device.
