5 Preparation
38 ARC 300 / ARC 350 Operating manual 900-350_IFU_V2.6_10296-S13-20100111-EN
Possible foot switch combinations
Foot switch
(type)
Connection
socket
Active output
(front)
Mode Operation
50
3 or 4 Bipolar Coag
X Change foot switch output:
Press key/display 44/48 for
1.5 sec. or with foot pedal
sensor (EP+)
2 Monopolar Coag
X Change foot switch output:
Press key/display 39 for
1.5 sec. or with foot pedal
sensor (EP+)
Single pedal
with/without sensor
(EP/EP+)
52
3 Bipolar Coag
X Change foot switch output:
Press key/display 44 for
1.5 sec. or with foot pedal
sensor (EP+)
50
3 or 4 Bipolar Cut
1)
/Coag
X Change foot switch output:
Press key/display 44/48 for
1.5 sec. or with foot pedal
sensor (DP+)
Double pedal
with/without sensor
(DP/DP+)
52
2 or 3 Monopolar
Cut/Coag
Bipolar Cut
1)
/Coag
X Change foot switch output:
Press key/display 39/44 for
1.5 sec. or with foot pedal
sensor (DP+)
1)
Only for ARC 350
The shift sensor on the foot switch is locked in programs 18, 19, and 20
for safety reasons.
Socket changeover must occur directly at the device.
