11 Technical specifications
82 ARC 300 / ARC 350 Operating manual 900-350_IFU_V2.6_10296-S13-20100111-EN
Setting Program
DryCUT 12
ARC350DC_SE_080124_1
0
50
100
150
200
250
10 100 1000 10000
P [W]
DryCut 100W
Blend 0-9
DryCut 200W
Blend 0-9
Measurement of resistances
• Diagram of power output P [W] as a
function of the load resistance R [Ω] for
the setting “DryCUT” = 200 W/100 W
ARC350DC_SE_080125_2
0
20
40
60
80
100
140
120
180
160
200
0 20 40 60 80 100 120 140 160 180 200
displayed value
P [W]
• Diagram of power output P [W] as a
function of the "DryCUT" setting.
Measured load resistance = 500 Ω
Blend 0-9
ARC350DC_SE_080124_3
0
200
600
1000
1400
400
800
1200
1600
1800
0 20 40 60 80 120100 140 160 180 200
displayed value
U [Vp]
• Diagram of HF output voltage U [Vp] as
a function of the "DryCUT" setting (idle
mode)
