BOWFLEX Ultimate Parts Reference Guide
4
Item No. Qty. Part No. Description
1 1 10001 LOWER LAT TOWER
2 1 10002 LEFT MAIN FRAME ASSEMBLY
3 1 10003 RIGHT MAIN FRAME ASSEMBLY
4 1 10004 SQUAT FRAME
5 1 10005 SQUAT PLATFORM
6 1 10011 ADJUSTABLE PULLEY SYSTEM
7 2 10012 ADJ. PULLEY SYST. BOLT SPACER
8 2 10074 ADJ. PULLEY SYST. LOCK KNOB
9 2 90177 PULLEY ASSEMBLY
10 1 10014 SEAT RAIL
11 1 10039 FOOT REST ASSEMBLY
13 1 10036 REAR LEG
14 1 10017 SEAT
21 1 10015 INCLINE BENCH REST
22 1 10016 INCLINE BENCH REST BACK
23 1 10049 ROD BOX w/ RODS
24 1 10044 ROD BOX FRAME
25 1 10018 BENCH
26 1 10035 BENCH REST BRACKET
27 2 90215 ROD CABLE
32 2 10007 SQUAT CABLE
33 4 50334 SNAP HOOK
35 1 90650 48” BAR
36 2 10073 SQUAT STRAP
37 1 10075 LARGE THREADED KNOB
38 2 90134 HAND GRIP/ANKLE CUFF
Item No. Qty. Part No. Description
39 1 90640 T-BAR w/ STRAP
41 3 90149 SCREW, 1/4" X 1-1/2" PHILLIPS HEAD
44 4 10182 SCREW, #10 X 3/4" SELF TAPPING
45 3 10183 SCREW, #10 X 1" SELF DRILLING
46 5 10103 BOLT, 3/8" X 3/4"
48 3 10107 BOLT, 3/8" X 2"
49 2 90193 BOLT, 3/8" X 2-1/2"
51 2 90139 BOLT, 3/8" X 3"
52 4 10125 BOLT, 3/8" X 4-3/4"
53 1 10126 BOLT, 3/8" X 5"
54 30 90138 WASHER, 3/8"
55 6 90156 WASHER, 1/4"
57 13 90196 NUT, 3/8" NYLON LOCK NUT
58 1 90222 RAIL END CAP
59 1 90217 LEG PRESS BELT
73 2 10177 REAR LEG BOLT KEEPER
74 2 10178 LEG PRESS BOLT KEEPER
75 8 10125 3/8” x 3/4’ SQUARE HEAD BOLT
76 1 10201 LOWER LAT CROWN
Parts List
Base Unit Assembly
