Routine Service and Maintenance
4.6
If you are checking the uid level after a period of use, the hydraulic system and
hydraulic uid will be very hot. Wear gloves when inspecting the hydraulic uid level.
7. Check hydraulic oil level, ll as needed with the proper hydraulic oil - be sure
engine is off.
a. The hydraulic oil dipstick can be reached through the opening in the front cover.
b. Unscrew the dipstick assembly and remove from the machine. (Item 1, Figure 4–7).
c. Make sure that the hydraulic uid is between the marker holes in the dip stick.
Figure 4-7 Hydraulic Fluid Level Dip Stick
d. Add the proper hydraulic uid (Chevron Rykon Premium ISO 46 hydraulic uid or
equivalent) until the uid level is 1/4” below marker hole in the dipstick.
• Do not over ll the hydraulic system. Damage to the hydraulic system might result.
CAUTION
NOTICE
To Next Page
