6 Service Manual Edition 12/07
Replacing assembly units
Brady IP Series Printer
2 Replacing assembly units
2.1 Device overview
Fig. 1: Overview
1
RS-232 serial interface
2 USB 2.0 High Speed Slave interface
3 Two USB master interfaces for
keyboard and scanner
4 Ethernet 10/100 Base T interface
5 CompactFlash card slot
6 Power supply socket
7 Power switch
8 PC card slot, type II
9 Cover
10 Media holder
11 Printhead assembly
12 Outer casing
13 Unlocking device
14 Printhead holder with printhead
15 Transport locking roller
16 Control panel
A
1 2 3 4 5 6 7 8
16
15
14
13
9
10
11
12
View A
