10 Service Manual Edition 12/07
Replacing assembly units
Brady IP Series Printer
2.5 Replacing the outer casing
Fig. 4: Replacing the outer casing
DANGER!
Danger to life and limb from electric shock!
⇒ Disconnect the device from the mains supply before opening the outer casing.
1
Two screws
2 Two screws
3 Outer casing
4 Cover
5 Print mechanism
6 Two cables
7 Ferrite
8 BDC PCB
cancel
pause
menu
feed
532
876
1 4
