2.11 Associating output
Associating the same output to several events or several areas (breakdowns, alarms, ...) means the function of the output.
Example: the output will activate when at least one area is in alarm mode if the generic alarm status is associated to the same stable-type output.
ASSOCIATION 15
OUTPUTS
*
OUTPUT PER AREA
▲
AREA OUTPUTS 01
AREA 001
▼
*
▼
▲
▼
▲
GEN. AREA ALR. 01
NO
+
-
▼
▲
Generic alarm area switched on: (Default:
NO
)
S A
For selecting the output to associate to the single area’s general alarm..
AREA SABOTAG. 01
NO
+
-
Area sabotage alarm output: (Default:
NO
)
S A
For selecting the output to associate to the single area’s sabotage alarm (inputs
tamper and 24h-type inputs).
TECH AREA ALR 01
NO
+
-
Area technical alarm output: (Default:
OUTPUT 004
)
S A
For selecting the output to associate to the single area’s technical alarm (technical-
type inputs).
AREA BURG ALR 01
NO
+
-
Area burglar-alarm output: (Default:
NO
)
S A
For selecting the output to associate to the single area’s burglary alarm.
AREA READY 01
NO
+
-
Area output ready: (Default:
NO
)
S A
For selecting the output to associate to the single area’s ready status (an area is
deemed ready when none of its associated inputs is open).
AREA ON 01
NO
+
-
Generic alarm area switched on: (Default:
OUTPUT 002
)
S A
For selecting the output to associate to the single area’s switched on or off status.
AREA BUZ. OUTP 01
NO
+
-
Area buzzer output: (Default:
NO
)
S A
For selecting the output to associate to the single area’s “input buzzer” (an input
can be associated to a buzzer function).
AREA TC OUTP. 01
NO
+
-
Area TC output: (Default:
OUTPUT 001
)
S A
For selecting the output to associate to the single area’s TC status.
The TC output is for blocking the sensors when the system is disinserted. It works
as follows (example for control unit exit n. 1 which when ON yields 13.8Vdc):
• itrunsat13.8Vwhentheareaisswitchedoff;
• withareaswitchedonandtheinputisopenduringtheexittime.
System breakdown output (generic breakdown warning): (Default:
OUTPUT 003
)
S A
For selecting the output to associate to the system’s breakdown status.
+
-
SYSTEM FAILURE
OUTPUT 003
Battery breakdown output: (Default:
OUTPUT 003
)
S A
For selecting the output to associate to the batteries’ breakdown status (control unit,
auxiliary power supply units).
+
-
BATTERY FAILURE
OUTPUT 003
Missing 230 Vac line output: (Default:
OUTPUT 003
)
S A
For selecting the output to associate to the cut off 230 Vac power supply (control unit).
+
-
230 NETWRK FAIL.
OUTPUT 003
▼
▲
