Page 6 - Programming Manual 24805480/14-11-2012 319F92C ver. 1.2 -The data and information in this manual may be changed at any time with no obligation on BRAHMS’s part to notify anyone of this.
ENGLISH
BUS RS485
BUS RS485 connection speed:
A
Allows configuration of the BUS RS485 speed from the following: 115.200, 38.400,
9.600 (default), 4.800, 2.400.
SYSTEM 02
*
BUS RS485
*
BAUD RATE RS485
115200
SYSTEM TEST
Input test:
F
S
A
Testing for open inputs can be done on either the whole system or just on some
selected areas.
SYSTEM 02
*
TEST
SYSTEM
Control unit tamper test:
F
S
A
For checking the control unit tamper-status
INPUT TEST
*=LAUNCH TEST
*
*
AREAS TO TEST
###
CRT-U TAMP. TEST
*=LAUNCH TEST
Control unit battery test:
F
S
A
For promptly checking control unit battery-status
CRT-U BATT. TEST
*=LAUNCH TEST
SIRENS TEST
*=LAUNCH TEST
Siren test:
F
S
A
For manually commanding the alarm relay output of the control unit.
OUTPUT TEST
*=LAUNCH TEST
Output test:
F
S
A
For manually commanding the system outputs.
ADDRESSING REMOTE INSERTERS
Automatic self-learning and addressing of inserters::
F
S
A
For learning the system’s inserters. Hold key near to inserter that you wish to
address with the address viewed on display.
SYSTEM 02
*
ADDRESSING
INSERTERS
*
SELF-LEARNING
KEY READERS..
ON INSERTER 01
POSITION NEAR KEY
SELF-LEARNED
INSERTERS
Inserters already self-learned:
F
S
A
If the inserters are already self learned a confirmation text is displayed.
