Symbol Explanation
Manufacturer
Danger of clamping hand or other body parts in equipment
Do not look directly into the laser beam or point laser beam into the patient’s
face or eyes
Laser radiation emitted from aperture
Do not stare into beam
Class 2 laser product
max. output 1mW wavelength 635 nm
Radio device
Consult accompanying documentation
When the D and line below it are lined up, the camera is perpendicular to the
base of the Camera Cart.
Markers on joints that identify the parking position.
Marker indicates correct transport position for the height of telescopic post.
Only move Camera Cart in transport position.
Only move Monitor Cart in transport position.
GENERAL INFORMATION
Technical User Guide Rev. 1.1 Curve Dual Navigation Station Ver. 1.2 11
