2.2.2 LAN Connection
LAN Ports
The LAN ports support:
• 10 Mbps, 100 Mbps, and 1000 Mbps connections
• Automatic MDI/MDI-X configurations
Figure 5
LED Status Indication
ACT/LINK LED ①
Off No link
Solid orange Linked
Flashing orange Data activity
Speed LED②
Off 10 Mbps connection
Orange 100 Mbps connection
Green 1 Gbps connection
Network Connection
Curve interfaces provide no means of separation according to IEC 60601-1:2005. It is
recommended to use an adequate separation device for the network (LAN) interface with a
rating of minimum 1 MOOP and a dielectric strength of minimum 1.5 kV.
Connecting Curve to a hospital network may create an ME system according to IEC
60601-1:2005. Ensure that hospital network components are compliant to the relevant IEC
standard.
Monitor Cart
24 Technical User Guide Rev. 1.1 Curve Dual Navigation Station Ver. 1.2
