Brainlab CURVE - Performing Electrical Tests

4.3 Performing Tests
4.3.1 Protective Earth Resistance
General Information
Connect the measurement tip of your measuring device with the conductive parts shown in the
table below and measure the resistance.
If a test does not pass, device must be repaired by Brainlab support. After repair, repeat the
entire electrical safety test from the beginning.
Protective Earth Resistance
Point Tested Measured Value Test
Passed?
Potential equalization port
Display fixation screw
Second display fixation
screw
Performing Tests
50 Technical User Guide Rev. 1.1 Curve Dual Navigation Station Ver. 1.2
