Brainlab CURVE - Camera Cart Details

2.3 Camera Cart
Components
②
③
④
⑥
①
⑧
⑨
⑤
⑦
Figure 6
No. Component
①
Motorized joint
②
Camera handle
③
Height adjustment handle
④
Telescopic post
⑤
Camera control unit
⑥
Camera Cart base
⑦
Transportation handle with cable hooks
⑧
Motor control unit
⑨
Camera
SYSTEM OVERVIEW
Technical User Guide Rev. 1.1 Curve Dual Navigation Station Ver. 1.2 25
