Brainlab CURVE - System Specifications (Physical & Technical)

5.3 System Specifications
5.3.1 Physical Characteristics
Camera Cart
Specification Value
Weight 87.5 kg
Footprint 726 x 725 mm
Max. Height 2530 mm
Monitor Cart
Specification Value
Weight 120 kg
Footprint 757 x 757 mm
Height 1499 mm
EM Base Station
Figure 12
Specification
Value
Height 350 mm
Width 200 mm
Length 100 mm
Weight 2.5 kg
COMPLIANCES AND SPECIFICATIONS
Technical User Guide Rev. 1.1 Curve Dual Navigation Station Ver. 1.2 65
