Brainlab CURVE - Electromagnetic Immunity, Curve System

5.4.3 Electromagnetic Immunity, Curve System
IEC 61000-4-2, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-8, IEC 61000-4-11
Immunity Test IEC 60601 Test Level and
Compliance Level
Electromagnetic Environment - Guidance
Electrostatic dis-
charge (ESD) IEC
61000-4-2
± 6 kV contact
± 8 kV air
Floors should be wood, concrete or ceramic
tile. If floors are covered with synthetic mate-
rial, the relative humidity should be at least
30%.
Electrical fast tran-
sient/burst IEC
61000-4-4
± 2 kV for power supply
lines
± 1 kV for input/output lines
Mains power quality should be that of a typi-
cal commercial or hospital environment.
Surge IEC
61000-4-5
± 1 kV line(s) to line(s)
± 2 kV line(s) to earth
Mains power quality should be that of a typi-
cal commercial or hospital environment.
Power frequency
(50/60 Hz) magnet-
ic field IEC
61000-4-8
3 A/m
Power frequency magnetic fields should be
at levels characteristic of a typical location in
a typical commercial or hospital environment.
Voltage dips, short
interruptions and
voltage variations
on power supply in-
put lines IEC
61000-4-11
<5% UT (>95% dip in UT)
for 0.5 cycle
40% UT (60% dip in UT) for
5 cycles
70% UT (30% dip in UT) for
25 cycles
<5% UT (>95% dip in UT)
for 5 s
Mains power quality should be that of a typi-
cal commercial or hospital environment. If the
Curve system user requires continued opera-
tion during power mains interruptions, it is
recommended that the Curve system be
powered from an uninterruptible power sup-
ply or a battery.
NOTE: U
T
is the AC mains voltage prior to application of the test level.
IEC 61000-4-6, IEC 61000-4-3
Immunity
Test
IEC 60601
Test Level
Compliance
Level
Electromagnetic Environment - Guidance
Conducted
RF IEC
61000-4-6-
3 Vrms
150 kHz to
80 MHz
3 V
Portable and mobile RF communications equip-
ment should be used no closer to any part of the
Curve system, including cables, than the rec-
ommended separation distance calculated from
the equation applicable to the frequency of the
transmitter.
Recommended separation distance:
d = 1.17√P
d = 1.17√P
80 MHz to 800 MHz
d = 2.3√P
800 MHz to 2.5 GHz
COMPLIANCES AND SPECIFICATIONS
Technical User Guide Rev. 1.1 Curve Dual Navigation Station Ver. 1.2 73
