4.4.3 Touch Current for Medical Electrical Systems
General Information
The touch current test for medical electrical systems repeats some of the steps in the standard
equipment leakage current test.
For more information on the standard equipment leakage current test, see page 51.
Test Overview
Connect the measurement tip of your measuring device with the conductive part and measure the
leakage current.
Measuring Test Points
Point Tested Measured Value Test
Passed?
On/off button
Screw on camera rotation
hinge
Camera pitch hinge
Screw on left under side of
Camera Cart transport han-
dle
Screw on left side of the
post fixation to the Camera
Cart transport handle
Electrical Safety Test - Medical Electrical System
60 Technical User Guide Rev. 1.1 Curve Dual Navigation Station Ver. 1.2
