5.4.5 Tested Cables
Use of Specified Cables
The use of accessories and cables other than those specified (with the exception of cables
sold by Brainlab as replacement parts), may result in increased emissions or decreased
immunity of the equipment.
For a navigation station the following shall apply: S-Video type cables provided by the user
shall be equipped with a ferrite on both ends (e.g., Würth Electronic Art. No. 742 711 31 or
equivalent). USB type cables provided by the user shall be equipped with a ferrite on both
ends (e.g., Würth Electronic Art. No. 742 712 22 or equivalent).
Cable Specifications
Curve system cables that have been tested for emission and immunity conformity:
Cable Specification
Camera Provided by Brainlab; 10 m long
Power Provided by Brainlab; 5 m long
Potential equalization cable Provided by Brainlab; 5 m long
Composite In
Coax cable (min. 0.5/3.7 diameter), shielded, terminated,
75 Ohm; max. 10 m long
Hospital Network (“Intraoper-
ative Data”)
CAT6 SFTP cable, shielded, not terminated, provided by Brain-
lab; 5 m long
USB (I-O-shield) USB 2.0/3.0 cable, shielded, not terminated
SDI In
Coax cable (min. 0.5/3.7 diameter), shielded, terminated,
75 Ohm; max. 10 m long
Microscope Provided by Brainlab; 10 m long
Converter Kit DVI to S-Video
Provided by Brainlab: S-Video cable 10m long, DVI to HDMI ca-
ble 2 m long, Power cable 5 m long, DVI Converter
Display Port
Display Port 1.2 cable, max. 5 m long, resolution up to
1920 x 1080 / 60 Hz
EM Tracking Unit Power Ca-
ble
5 m
EM Tracking Unit Data Cable 5 m
Supported Output Resolutions
The table below specifies the supported output resolutions for display output available on Curve.
For more information on output resolution, contact Brainlab support.
Displays
Color Coding Connector Signal Type Format
Display Out 8-bit RGB Display Port DisplayPort 1.2
1920x1080@60Hz
1920x1080@60Hz
3840x2160@30Hz
3840x2160@60Hz
Compliances
