Brainlab CURVE - Technical Specifications

5.3.2 Technical Specifications
Monitor Cart and Medical Computer Unit
Specification Value
Electrical Specifications
AC input
100-120 V ± 10%
200-240 V ± 10%
Frequency 50 - 60 Hz
Power consumption
7 A @ 100 Vac
3.5 A @ 240 Vac
CMOS Battery 3V CR2032 Lithium Battery
Processor Intel Xeon 3700 MHz
RAM 8 GB
Supported I/O (Availability De-
pends on System Configura-
tion)
• 4x USB 2.0 2x USB 3.0
• Potential equalization
• Camera
• 2x SDI Video In, 2x CVBS Video In
• S-Video In
• 2x Gigabit Ethernet
Mass Storage Internal Hard Disk 2.5” 320 GB
Audio
• Loudspeaker integrated in display
• Stereo sound system with docking station
Display
LCD TFT Display 27”, 16M Colors
The graphic card delivers a progressive single stream signal.
The 3D content is created by software (Additional software may
be required). An external display must support 3D line by line
technology to display the 3D content correctly.
Touchscreen Projected Capacitive Touch Screen
Weight 120 kg
Camera Cart
Specification Value
Input Voltage 24 Vdc
Power Consumption 15 W
Tracking Accuracy 0.3 mm RMS (Root Mean Square)
DVI Converter
Please refer to the Brainlab Instruction Leaflet, Converter Kit DVI to S-Video.
Wireless LAN Specifications
Specification
Value
Frequency bands 2.4 GHz and 5 GHz
Data Modulation DSSS, OFDM for 2.4 MHz and OFDM for 5 GHz
COMPLIANCES AND SPECIFICATIONS
Technical User Guide Rev. 1.1 Curve Dual Navigation Station Ver. 1.2 69
